Dirui Hematology Analyzer

DIRUI Hematology Analyzer BCC3000B

Feature
Sample Volume : Prediluted 20ul
Whole Blood 13ul
Aperture Diameter : WBC 100um
RBC: 70um
Wavelength : 540 nm
Throughput : 60 samples per hour
Dilution rations :
Whole Blood Capillary Blood
WBC/HGB 1:308 1:428
RBC/PLT 1:44872 1:43355
Lyse Volume Whole Blood Capillary Blood 0.5 ml 0.36 ml

Technical Parameter
White Blood Cell or leukocyte WBC
Lymphocyte LYM#
Mid-sized cell MON#
Granulocyte GRA#
Lymphocyte percentage LYM%
Mid-sized cell percentage MON%
Granulocyte percentage GRA%
Red Blood Cell or erythrocyte RBC
Hemoglobin Concentration HGB
Mean Corpuscular (erythrocyte) Volume MCV
Mean Cell (erythrocyte) Hemoglobin MCH
Mean Cell (erythrocyte) Hemoglobin Concentration MCHC
Red Blood Cell (erythrocyte) Distribution Width Coefficient of Variatio RDW-CV
Red Blood Cell (erythrocyte) Distribution Width Standard Deviation RDW-SD
Hematocrit HCT
Platelet PLT
Mean Platelet Volume MPV
Platelet Distribution Width PDW
Plateletcrit PCT
Platelet Larger cell ratio P-LCR
WBC Histogram
RBC Histogram
PLT Histogram
Storage: 1000 testing results, 570 QC results
Language: English
Operation Environment:
Temperature :15℃~35℃;
Humidity : 30%~85%;
Air Pressure : 76kPa~106kPa
Input/Output: RS-232, Internal thermal printer, 1 bar code reader (optional),1 parallel
printer(optional)
Data transmitting rate: 19200bps
Power supply: 100~240VAC ,50/60Hz
Fuse: 250V 2A
Power: 200W
Weight: 25Kgs
Dimension: 460(L)×390(W)×410(H)
Electromagnetic Compatibility (EC)
Accord with EMC test standard EN61326:1997+A1 1998+A2 2001+A3 2003;
Sound pressure : Max. 85dB
